مشخصات فیزیکی |
ابعاد | 24.4x24.4 سانتی متر |
فرم فاکتور | microATX |
پردازنده و چیپ ست |
نوع سوکت پردازنده | Intel LGA 1700 |
چیپست | Intel B660 |
پردازنده های پشتیبانی شده | - 12th Generation Intel® Core™, Pentium® Gold and Celeron® Processors
|
پشتیبانی از RAID | RAID 0, RAID 1, RAID 5, and RAID 10 |
حافظه رم |
نوع حافظه پشتیبانی شده | DDR4 |
تعداد اسلات حافظه | چهار عدد |
پیکربندی حافظه | دو کاناله |
حداکثر حافظه پشتیبانی شده | 128 گیگابایت |
پروفایل حافظه XMP | دارد |
توضیحات حافظه | - فرکانس رم: DDR4 5333(O.C.)/ DDR4 5133(O.C.)/DDR4 5000(O.C.)/4933(O.C.)/4800(O.C.)/ 4700(O.C.)/ 4600(O.C.)/ 4500(O.C.)/ 4400(O.C.)/ 4300(O.C.)/4266(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3800(O.C.) / 3733(O.C.) / 3666(O.C.) / 3600(O.C.) / 3466(O.C.) / 3400(O.C.) / 3333(O.C.) / 3300(O.C.) / 3200/3000/2933/2666/2400/2133 MHz memory modules
|
کارت گرافیک |
سایر توضیحات کارت گرافیک | - Onboard Graphics:
- 1x D-Sub port, supporting a maximum resolution of 1920x1200@60 Hz
- 1x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz
- * Support for HDMI 2.1 version and HDCP 2.3.
- ** Support native HDMI 2.1 TMDS compatible ports.
- 1x DisplayPort, supporting a maximum resolution of 4096x2304@60 Hz
- * Support for DisplayPort 1.2 version and HDCP 2.3
- 1x DisplayPort, supporting a maximum resolution of 4096x2304@60 Hz
- * Support for DisplayPort 1.2 version.
|
اتصالات داخلی |
اسلات PCI Express x1 | یک عدد |
کانکتور SATA 3.0 | چهار عدد |
کانکتور M.2 | دو عدد |
کانکتورهای برق | - 1x 24-pin ATX main power connector
- 1x 8-pin ATX 12V power connector
|
توضیحات تکمیلی هدرها | - 1x CPU fan header
- 3x system fan headers
- 1x addressable LED strip header
- 1x RGB LED strip header
- 2x M.2 Socket 3 connectors
- 4x SATA 6Gb/s connectors
- 1x front panel header
- 1x front panel audio header
- 1x USB 3.2 Gen 1 header
- 2x USB 2.0/1.1 headers
- 1x S/PDIF Out header
- 2x Thunderbolt™ add-in card connectors
- 1x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only)
- 1x serial port header
- 1x parallel port header
- 1x reset button
- 1x Q-Flash Plus button
- 1x reset jumper
- 1x Clear CMOS jumper
|
پنل پشتی |
پورت PS/2 | یک عدد مخصوص کیبورد و موس |
پورت D-Sub | یک عدد |
پورت HDMI | دارد |
پورت DisplayPort | دارد |
پورت LAN | یک عدد |
کارت شبکه LAN | Intel® 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps) |
کانالهای صوتی | 2/4/5.1/7.1 کانال |
جک 3.5 میلیمتری | 6 عدد |
توضیحات کارت صدا | - Realtek® Audio CODEC
- High Definition Audio
- Support for S/PDIF Out
|
توضیحات تکمیلی پورتها | - 1x USB Type-C® port, with USB 3.2 Gen 2 support
- 1x USB 3.2 Gen 2 Type-A port (red)
- 2x USB 3.2 Gen 1 ports
- 2x USB 2.0/1.1 ports
- 1x HDMI port
- 2x DisplayPorts
- 1x RJ-45 port
- 6x audio jacks
|
سایر مشخصات |
مشخصات تکمیلی | - پشتیبانی از سیستم عامل های Windows 11 and 10 64-bit
- Expansion Slots: 1x PCI Express x16 slot, running at x16 (PCIEX16) - 1x PCI Express x16 slot, running at x4 (PCIEX4) - 1x PCI slot - 1x PCI Express x1 slot
|
سایر توضیحات بایوس | - 1x 256 Mbit flash
- Use of licensed AMI UEFI BIOS
- PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
|
