مشخصات فیزیکی |
ابعاد | 24.4x24.4 سانتی متر |
فرم فاکتور | microATX |
پردازنده و چیپ ست |
نوع سوکت پردازنده | Intel LGA 1700 |
پردازنده های پشتیبانی شده | - 12th Generation Intel® Core™, Pentium® Gold and Celeron® Processors
|
حافظه رم |
نوع حافظه پشتیبانی شده | DDR4 |
تعداد اسلات حافظه | چهار عدد |
پیکربندی حافظه | دو کاناله |
حداکثر حافظه پشتیبانی شده | 128 گیگابایت |
پروفایل حافظه XMP | دارد |
توضیحات حافظه | - فرکانس رم: DDR4 4400(O.C.)/ 4300(O.C.)/4266(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3800(O.C.) / 3733(O.C.) / 3666(O.C.) / 3600(O.C.) / 3466(O.C.) / 3400(O.C.) / 3333(O.C.) / 3300(O.C.) /3200/3000/2933/2666/2400/2133 MHz memory modules
- Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)
- Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
|
کارت گرافیک |
سایر توضیحات کارت گرافیک | - Onboard Graphics: 1x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz - 1x DisplayPort, supporting a maximum resolution of 4096x2304@60 Hz
|
اتصالات داخلی |
کانکتورهای برق | - 1x 24-pin ATX main power connector
- 1x 8-pin ATX 12V power connector
|
توضیحات تکمیلی هدرها | - 1x CPU fan header
- 3x system fan headers
- 2x addressable LED strip headers
- 2x RGB LED strip headers
- 2x M.2 Socket 3 connectors
- 4x SATA 6Gb/s connectors
- 1x front panel header
- 1x front panel audio header
- 1x USB Type-C® header, with USB 3.2 Gen 2 support
- 1x USB 3.2 Gen 1 header
- 2x USB 2.0/1.1 headers
- 1x S/PDIF Out header
- 2x Thunderbolt™ add-in card connectors
- 1x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only)
- 1x serial port header
- 1x reset button
- 1x Q-Flash Plus button
- 1x reset jumper
- 1x Clear CMOS jumper
|
پنل پشتی |
کارت شبکه LAN | 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps) |
توضیحات کارت شبکه | - Realtek® Audio CODEC
- High Definition Audio
- Support for S/PDIF Out
|
کانالهای صوتی | 2/4/5.1/7.1-channel |
توضیحات تکمیلی پورتها | - 3x USB 3.2 Gen 1 ports
- 5x USB 2.0/1.1 ports
- 2x SMA antenna connectors (2T2R)
- 1x HDMI 2.1 port
- 1x DisplayPort
- 1x RJ-45 port
- 3x audio jacks
|
سایر مشخصات |
ویژگیهای خاص | - Support for APP Center
- Support for Q-Flash Plus
- Support for Q-Flash
- Support for Xpress Install
|
مشخصات تکمیلی | - Onboard Graphics: 1x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz - 1x DisplayPort, supporting a maximum resolution of 4096x2304@60 Hz
- USB--> Chipset: 1x USB Type-C® port with USB 3.2 Gen 2 support, available through the internal USB header - 5x USB 3.2 Gen 1 ports (3 ports on the back panel, 2 ports available through the internal USB header) - 1x USB 2.0/1.1 port on the back panel -
- Chipset+2 USB 2.0 Hubs: 8x USB 2.0/1.1 ports (4 ports on the back panel, 4 ports available through the internal USB headers)
- Expansion Slots: 1x PCI Express x16 slot, running at x16 (PCIEX16) - 1x PCI Express x16 slot, running at x4 (PCIEX4)
|
سایر توضیحات بایوس | - 1x 256 Mbit flash
- Use of licensed AMI UEFI BIOS
- PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
|
