مشخصات فیزیکی |
ابعاد | 23.0×21.5 سانتی متر |
فرم فاکتور | microATX |
پردازنده و چیپ ست |
نوع سوکت پردازنده | Intel LGA 1700 |
چیپست | Intel H610 |
پردازنده های پشتیبانی شده | - 12th Generation Intel Core, Pentium Gold and Celeron
|
حافظه رم |
نوع حافظه پشتیبانی شده | DDR4 |
تعداد اسلات حافظه | دو عدد |
پیکربندی حافظه | دو کاناله |
حداکثر حافظه پشتیبانی شده | 64 گیگابایت |
پروفایل حافظه XMP | دارد |
توضیحات حافظه | - Support for DDR4 3200/3000/2933/2666/2400/2133 MHz memory modules
- 2x DDR4 DIMM sockets supporting up to 64 GB (32 GB single DIMM capacity) of system memory
- Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)
- Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
|
کارت گرافیک |
اسلات PCI Express x16 | یک عدد |
اتصالات داخلی |
اسلات PCI Express x1 | یک عدد |
توضیحات تکمیلی هدرها | - 1x 24-pin ATX main power connector
- 1x 8-pin ATX 12V power connector
- 1x M.2 Socket 3 connector
- 4x SATA 6Gb/s connectors
- 1x CPU fan header
- 2x system fan headers
- 1x RGB LED strip header
- 1x front panel header
- 1x front panel audio header
- 1x USB 3.2 Gen 1 header
- 2x USB 2.0/1.1 headers
- 1x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only)
- 1x serial port header
- 1x Clear CMOS jumper
|
توضیحات تکمیلی قسمت ذخیرهسازی (Storage) | - 1x M.2 connector (Socket 3, M key, type 2260/2280 PCIe 3.0 x4/x2 SSD support)
- 4x SATA 6Gb/s connectors
|
پنل پشتی |
توضیحات کارت شبکه | - Intel® GbE LAN chip (1 Gbps/100 Mbps)
|
کارت صدا | Realtek® Audio CODEC |
کانالهای صوتی | 2/4/5.1/7.1-channel |
توضیحات تکمیلی پورتها | - 1x PS/2 keyboard port
- 1x PS/2 mouse port
- 1x D-Sub port
- 1x HDMI 2.0 port
- 2x USB 3.2 Gen 1 ports
- 4x USB 2.0/1.1 ports
- 1x RJ-45 port
- 3x audio jacks
|
سایر مشخصات |
ویژگیهای خاص | - Support for APP Center
- Support for Q-Flash
- Support for Xpress Install
|
سیستم عاملهای قابل پشتیبانی | Windows ۱۱ ۶۴-bit Windows ۱۰ ۶۴-bit |
مشخصات تکمیلی | - کارت گرافیک انبرد:
- 1x D-Sub port, supporting a maximum resolution of 1920x1200@60 Hz
- 1x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz
- * Support for HDMI 2.1 version and HDCP 2.3.
- ** Support native HDMI 2.1 TMDS compatible ports
|
سایر توضیحات بایوس | - 1x 256 Mbit flash
- Use of licensed AMI UEFI BIOS
- PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
|
