پردازنده و چیپ ست |
نوع سوکت پردازنده | Intel LGA 1700 |
چیپست | Intel Z690 |
پردازنده های پشتیبانی شده | - 12th Generation Intel® Core™, Pentium® Gold and Celeron® Processors
|
پشتیبانی از RAID | RAID 0, RAID 1, RAID 5, and RAID 10 |
حافظه رم |
نوع حافظه پشتیبانی شده | DDR۵ |
تعداد اسلات حافظه | چهار عدد |
پیکربندی حافظه | دو کاناله |
حداکثر حافظه پشتیبانی شده | 128 گیگابایت |
پروفایل حافظه XMP | دارد |
توضیحات حافظه | - فرکانس رم: DDR5 6000(O.C.) / 5800(O.C.) / 5600(O.C.) / 5400(O.C.) / 5200(O.C.) / 4800 / 4000 MHz memory modules
- Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)
- Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
|
کارت گرافیک |
سایر توضیحات کارت گرافیک | - Onboard Graphics:
- 1x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz
- * Support for HDMI 2.1 version and HDCP 2.3.
- ** Support native HDMI 2.1 TMDS compatible ports.
- 1x DisplayPort, supporting a maximum resolution of 4096x2304@60 Hz
- * Support for DisplayPort 1.2 version and HDCP 2.3
|
اتصالات داخلی |
کانکتورهای برق | - 1x 24-pin ATX main power connector
- 1x 8-pin ATX 12V power connector
- 1x 4-pin ATX 12V power connector
|
توضیحات تکمیلی هدرها | - 1x CPU fan header
- 1x water cooling CPU fan header
- 3x system fan headers
- 1x system fan/water cooling pump header
- 2x addressable LED strip headers
- 2x RGB LED strip headers
- 4x M.2 Socket 3 connectors
- 6x SATA 6Gb/s connectors
- 1x front panel header
- 1x front panel audio header
- 1x USB Type-C® header, with USB 3.2 Gen 2 support
- 1x USB 3.2 Gen 1 header
- 2x USB 2.0/1.1 headers
- 2x Thunderbolt™ add-in card connectors
- 1x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only)
- 1x reset button
- 1x reset jumper
- 1x Q-Flash Plus button
- 1x Clear CMOS jumper
|
پنل پشتی |
کارت شبکه LAN | Realtek® 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps) |
کانالهای صوتی | 7.1 کانال |
توضیحات کارت صدا | - Realtek® ALC1220-VB CODEC
- High Definition Audio
- two-channel analog output
- Support for S/PDIF Out
|
توضیحات تکمیلی پورتها | - 1x USB Type-C® port, with USB 3.2 Gen 2x2 support
- 2x USB 3.2 Gen 2 Type-A ports (red)
- 3x USB 3.2 Gen 1 ports
- 4x USB 2.0/1.1 ports
- 1x HDMI port
- 1x DisplayPort
- 1x RJ-45 port
- 1x optical S/PDIF Out connector
- 2x audio jacks
|
سایر مشخصات |
مشخصات تکمیلی | - پشتیبانی از سیستم عامل های Windows 11 and 10 64-bit
- Expansion Slots: 1x PCI Express x16 slot, running at x16 (PCIEX16) - 2x PCI Express x16 slots, running at x4 (PCIEX4_1, PCIEX4_2)
- Storage Interface-->CPU:1x M.2 connector (Socket 3, M key, type 2260/2280/22110 PCIe 4.0 x4/x2 SSD support) (M2A_CPU)
- Chipset:2x M.2 connector (Socket 3, M key, type 2260/2280/22110 PCIe 4.0 x4/x2 SSD support) (M2P_SB, M2Q_SB) -1x M.2 connector (Socket 3, M key, type 2260/2280/22110 SATA and PCIe 4.0 x4/x2 SSD support) (M2M_SB)- 6x SATA 6Gb/s connectors
|
سایر توضیحات بایوس | - 1x 256 Mbit flash
- Use of licensed AMI UEFI BIOS
- PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
|
